Dungeon Crawler

The Dungeon Crawler is MOSFET based distortion pedal that’s designed to take a clean amp all the way to a death metal tone. Or a doom metal tone, or a black metal tone.. an extreme metal tone!

Based around 3 high gain MOSFET stages and 6 gyrator EQ stages, the Crawler is voiced to emphasize pick attack, high gain, and aggressive tone. The Grind knob adds the output of a silicon rectifier to take the tone even further while the custom comparator based noise gate keeps your extreme tone under control.

MSRP: $249 USD

Click here to find a dealer near you

Features

  • High Gain MOSFET Design
  • Active 6 Band EQ using gyrator (op-amp simulated inductor) stages
  • Boost Stomp for a nice increase in both gain and volume
  • Custom comparator based noise gate
  • High quality analog signal path with film capacitors
  • Premium parts and components throughout
  • True Bypass with soft touch relay switching
  • Full control over wet/dry mix
  • Top mounted audio and power jacks
  • Designed and handmade in B.C., Canada

Knobs

  • Gain – Increases the amount of distortion
  • Grind – Blends in a silicon rectifier for a grindier tone
  • Volume – Controls the effect signal level
  • Lows – Adjust the low frequencies, post gain
  • Lower Mids – Adjust frequencies around 420Hz, post gain
  • Upper Mids – Adjust frequencies around 1000Hz, post gain
  • Highs – Shelving treble filter at 3kHz, post gain
  • Mix – Adjusts the balance between the input signal (Dry) and the effect (Wet) signal
  • Thick – 130Hz pre-gain filter
  • Presence – Resonant 1000Hz filter, post gain
  • Gate– Turn down for no gate, increase for stronger gate
  • Boost – Engage for increase in Gain and Volume
  • Bypass – Engage or disengage the effect

Gallery

Videos

Operation

  • Input/Output Impedance: 500kΩ/1kΩ
  • 100mA @ 9VDC, 2.1mm centre negative plug
  • True Bypass with soft touch relay switching
